Peterborough: A 2,570m2 Horizontal sub-surface flow reed bed treating hydrocarbon loaded run-ff with peak flows of 1,420 m3/day.

This wetland was built for groundwater remediation on the site of a former oil refinery at the State University of New York's Wellsville campus 2008

  • Adapted „French system“ for a nursing home, Hogar de Ancianos Sta. Ana y San Joaquín y Asociación Ayuda Me Perú
  • All treated wastewater is reused for irrigation of agricultural used area
  • The 2 staged wetland system treats the domestic effluent of 55 residents and employees
  • The pre-treatment is carried out on the surface of an planted, vertical flowed gravel bed wetland with 2 charging points, used alternately (2 and 2 days)
  • The post-treatment is carried out in an planted vertical flowed sand bed wetland with 4 divisions to maintain always the biologically activity in all parts of the wetland

Design, Construction and Operation and mantainmance by Rotaria del Perú, online monitoring by SCADAweb

Client: Skövde Municipality
Location: Skövde, Sweden
Established: 2003
Number of basins: 10
Sludge type: Activated sludge and digested sludge
Sludge volume: 1,200 Tonnes DS/year
PE, amount: 50,000

The municipal centralised treatment plant (a classic activated sludge technology) for the wastewater produced by the municipality of Jesi (Ancona province – central Italy) has been upgraded in the year 2002, with the realisation of a new “nitrification-denitrification” compartment and a hybrid Constructed Wetland as polishing stage.

Seefood processing plant where the wastewater from cleaning fish and shellfish is treated in a VF wetland planted with papyrus.

The effluent is reused after ozonisation in the plant.

Client: Skive Municipality

Location: Skive, Denmark

Established: 1998

Number of basins: 18

Sludge type: Activated sludge

Sludge volume: 1,375 tonnes DS/year

PE, amount: 123,000



Saint Bonnet le Froid : a 900 m², vertical flow reed bed (French system) plus a 600 m² second stage unsaturated vertical flow red bed for the treatment of  domestic effluent from a village with variable population.

A 10 years old CW multistage system (5 stages: Imhoff+HF+VF+HF+FWS) treating the municipal wastewater for a town of 3500 inhabitants.
